PANEL INTERFACES > D-SUB
DAS-IPS-16
Bulkhead Panel for serial lines
 DAS-IPS-16      Price: 600  Euro
Add to Chart
 Part Numbers
DAS-IPS-16
19" 2U Bulkhead Panel for Serial lines RS-232 and RS-422
DAS-IPS-16-K
19" 2U Bulkhead Panel for Serial lines RS-232 and RS-422 or digital I/O signals like ARINC-429 Avionic bus.
Connector kit with turned pins and plug connectors
 Specifications
Pannel size19" - 2U (483 x 884,8 x 4mm)
MaterialAlluminium alloy 6082
Front connectors16 DB9-F Harting 09661117501
Rear connectors8 DB25-F Harting 09663117503
4 DB25-M Harting
09653217703
Connection Kit
- 16 Front panel Plug Jumper
- Rear Plug Kit with turned pins and
6 Male + 4 Female D-SUB 25 pole connectors

Turned PinsFemale: Harting 09670008476
Male: Harting 09670008576
Max. Current1A
Max.Voltage28V
TemperatureIndustrial range -20/+70° C.
Certifications
CE - IEC/EN 61010
 DAS-IPS-16-K  Price: 850  Euro
Add to Chart
DAS-IPS-16 is the rackmount solution for test and diagnostic from 1 to 16 channel of Serial lines RS-232 and/or RS-422/485 or ARINC-429 Avionic Bus.

Perfect Labeling
These Patch Panel are made in Anodized Alluminum alloy. Written and logos  are made “on demand” and permanently engraved with a laser machine.
